5-10 BA DT10 en - Edition 1.5 * * dt10b510.fm
Maintenance
Cleaning the filter cup/replacing the filter cartridge
Fuel is extremely flammable, and explosive under certain circumstances.
Accident hazard!
☞No smoking in the job site, no open flames or sparks.
☞Once the filter cup is back in position, check for leaks and ensure that all gas-
oline spills have been wiped away before starting the engine.
☞Set fuel cock A to S (OFF)
☞Unscrew filter cup B with a suitable tool by loosening ring C
☞Remove filter cup B and O-ring D, and wash with a nonflammable solvent.
☞Allow filter cup B to dry thoroughly
☞Take out filter element E and rinse it with diesel fuel or replace it
☞Screw filter cup B back on again with a suitable tool by tightening ring C
☞Set fuel cock A to O (ON) and check for leaks
Dispose of the drained fuel in an environmentally friendly manner.
Fig. 74: Filter cup
B
O
S
A
C
D
E
