4.10 Generator and Receptacle Wiring

BOM Revision See

Graphic:

Revision See

Graphic:

Revision See

Graphic:

0009366 123 & higher wc_gr004692 106–122 wc_gr003171 105 & lower wc_gr002614

0009367 124 & higher wc_gr004692 106–123 wc_gr003171 105 & lower wc_gr002614

0009369 124 & higher wc_gr004692 106–123 wc_gr003171 105 & lower wc_gr002614

0009467 131 & higher wc_gr004692 107–130 wc_gr003171 106 & lower wc_gr002614

0009468 133 & higher wc_gr004692 107–132 wc_gr003171 106 & lower wc_gr002614

0009459 133 & higher wc_gr004692 107–132 wc_gr003171 106 & lower wc_gr002614

0620001 127 & higher wc_gr004692 106–126 wc_gr003171 105 & lower wc_gr002614

0620002 129 & higher wc_gr004692 106–128 wc_gr003171 105 & lower wc_gr002614

0620003 129 & higher wc_gr004692 107–128 wc_gr003171 106 & lower wc_gr002614

0620350 wc_gr004692

0620351 wc_gr004692

0620352 wc_gr004692

Ref. Description Ref. Description

1 Lug safety limit switch 15 Voltage selector switch

2 Mechanical lugs 16 Generator

3 Plug 3 - current transformer inputs 17 Voltage regulator

4 Plug 4 - line voltage inputs 18 Voltage adjustment rheostat

5 Shunt 19 Terminal Block

6 120V 20A GFI receptacle 20 Exciter

7 120V breaker 21 Stator

8 240V 50A breaker 22 Rotor

9 240V 30A breaker 23 Rectifier

10 240V 50A receptacle 24 Rotor winding

11 240V 30A receptacle 25 Main stator windings

12 Engine control module 26 Auxiliary Stator Winding

13 Main breaker 27 Stator

14 Bond bar 28 Terminal Strip
