Maintenance G 50/G 70/G 85
wc_tx000484gb.fm 60
4.11 Trailer Wiring
Ref. Description
1 Front right side amber light
2 Front left side amber light
3 Trailer plug
4Battery
5 Brake solenoid
6 Right rear taillight
7 License plate holder lights
8 Left rear taillight
9 Rear right side red light
10 Rear left side red light
Ref. Wire Colors Rear Lights Side Lights Harness
B BLACK Ground Ground Battery charge
Br BROWN Taillight Tail, side and license plate
L BLUE
R RED Brake light Power Electric brakes
Y YELLOW Left brake light and directional
G GREEN Right brake light and directional
W WHITE Ground
