Factory-Installed Options Mobile Generators
wc_tx000380gb.fm 80
5.7 Temperature-Activated Shutters
See Graphic: wc_gr001706, wc_gr001707
The shutters (a) are mounted to the top of the generator enclosure.
The shutters are designed to keep the engine compartment warm, thus
increasing engine temperature during cold weather operation. The
shutters are activated through a wax-pellet actuator (b) that is
connected to the generator's cooling system. As radiator coolant
warms, the wax-pellet actuator engages a linkage (c) that opens the
shutters. As the coolant cools, the shutters close.
5.8 Lockable Battery Disconnect
See Graphic: wc_gr004338
A lockable ON/OFF switch is available which disconnects the battery.
A padlock (not included) securely locks the switch in the OFF position.
If equipped, the battery disconnect switch is mounted to the upper skid
beneath the access door on either the right or left side of the machine.
NOTICE: Do not use the battery disconnect switch while the engine is
running. Damage to electrical components may occur.
wc_gr001707
a
