Maintenance G 50/G 70/G 85
wc_tx000484gb.fm 72
Engine
Wires
BOM Revision See Graphic: Revision See Graphic:
0009369 124 & higher wc_gr004614 123 & lower wc_gr002616
0009459 133 & higher wc_gr004614 132 & lower wc_gr002616
0620003 129 & higher wc_gr004614 128 & lower wc_gr002616
0620350 wc_gr004614
0620351 wc_gr004614
0620352 wc_gr004614
Ref. Description Ref. Description
1 Safety interlock switch 11 Intake heater relay
2 Mechanical lugs 12 Plug 2 - engine start outputs
3 Main circuit breaker 13 Run/off/auto switch
4 Shunt 14 Battery
5 Emergency Stop switch 15 10A fuse
6 Engine control module 16 Starter relay
7 Plug 1 - engine sender inputs 17 Starter
8 Remote start contacts 18 Alternator
9 Fuel level sender 19 Terminal block
10 Intake heater
Ref. Description Ref. Description
18 Battery + 62 Fuel Level
53 Battery + 63 Crank
56 Cold Crank Delay 64 Run/Fuel
59 Battery - 73 Remote Annunciator
60 Remote Start 75 Remote Annunciator
61 E-Stop
Wire Colors
B Black R Red Y Yellow Or Orange
G Green T Tan Br Brown Pr Purple
L Blue V Violet Cl Clear Sh Shield
P Pink W White Gr Gray LL Light blue
