Technical Data GPS 8500/GPS 9700
wc_td000255gb.fm 54
CARB Compliant Machines
Engine power rating
Gross power rating per SAE J1995. Actual power
output may vary due to conditions of specific use.
0008287
Item No. GPS 9700
Engine
Engine Type 2 cylinder, 4-cycle,
air-cooled, gasoline engine
Engine Make Briggs and Stratton
Engine Model Vanguard 356447
Max. rated power @ rated speed
kW (Hp)
13.4 (18) @ 3600 rpm
Displacement
cm
3
(in
3
)
570 (34.75)
Spark Plug Champion RC12YC
Electrode Gap
mm (in.)
0.76 (0.030)
Starter
type / V
Electric / 12
Alternator
amp
16
Operating speed
rpm
3600
Auto Idle Speed
rpm
2200
Valve Clearance (cold)
mm (in.)
0.10–0.16 (0.004–0.006)
Air Cleaner
type
Dual element
Battery
V/size/CCA
12 / 22NF / 230
Engine Lubrication
oil grade
service class
SAE 10W30
SG, SF, or SE
Engine Oil Capacity
l (qts.)
1.6 (1.7)
Fuel
type
Regular unleaded gasoline
Fuel Tank Capacity
l (gal.)
28 (7.4)
Fuel Consumption
l (gal.)/hr.
6.21 (1.64)
To Next Page
