Wacker Neuson IRFU Series User Manual

13 Technical data
46
100_0101_td_0001.fm
Designation Unit IRFU 45/230/10 IRFU 45/230 CH
Item no. 5100008834 0610253
Rated current A 4,8 4,8
Rated voltage V 220 - 240 220 - 240
Rated frequency Hz 50 – 60 50 – 60
Rated input power ** kW 0,88 0,88
Phases ~ 1 1
Vibration range in air mm (in) 2,3 (0.09) 2,3 (0.09)
Vibrations rpm 12,000 12,000
Hz 200 200
Vibrator head diameter mm (in) 45 (1.8) 45 (1.8)
Outer diameter of
protective hose
mm (in) 31 (1.2) 31 (1.2)
Length of vibrator head mm (in) 382 (15.0) 382 (15.0)
Length of protective hose m (ft) 10 (32.8) 5 (16.4)
Length of power cable *** m (ft) 15,0 (49.2) 15,0 (49.2)
Weight kg (lb) 20,0 (44.1) 16,0 (35.3)
Plug IEC 60884-1, SS Vll-CEE 7 Typ J, SEV 1011
Engine type Asynchronous motor Asynchronous motor
Oil specification 4 UH1- 46N 4 UH1- 46N
Oil quantity l 0,010 0,010
Class rating l l
Protection class IP 67 IP 67
Switch-off temperature °C (°F) 150 (302.0) 150 (302.0)
Storage temperature
range
°C (°F) -20 – +60
(-4 - +140)
-20 – +60
(-4 - +140)
Operating temperature
range
°C (°F) -10 – +40
(+14 – +104)
-10 – +40
(+14 – +104)
Sound pressure level L
pA
* dB(A) 79,0 79,0
Standard DIN EN ISO 11201
