13 Technical data
54
100_0101_td_0001.fm
Designation Unit IRFU 65/230/5 GV
Item no. 5100015351
Rated current A 10,0
Rated voltage V 220 - 240
Rated frequency Hz 50 – 60
Rated input power ** kW 1,84
Phases ~ 1
Vibration range in air mm (in) 2,5
Vibrations rpm 12000
Hz 200
Vibrator head diameter mm (in) 65 (2.6)
Outer diameter of
protective hose
mm (in) 40 (1.6)
Length of vibrator head mm (in) 490 (15.7)
Length of protective hose m (ft) 5 (16.4)
Length of power cable *** m (ft) 15,0 (49.2)
Weight kg (lb) 29,0 (63.9)
Plug CEE 7/7, Typ EF
Engine type Asynchronous motor
Oil specification 4 UH1- 46N
Oil quantity l 0,010
Class rating l
Protection class IP 67
Switch-off temperature °C (°F) 150 (302.0)
Storage temperature
range
°C (°F) -20 – +60
(-4 - +140)
Operating temperature
range
°C (°F) -10 – +40
(+14 – +104)
Sound pressure level L
pA
* dB(A) 79,0
Standard DIN EN ISO 11201
