16 Technical data
100_0101_td_0017.fm 39
16.3 Flexible shaft-S (optional)
16.4 Vibrator head standard (optional)
Designation Unit SM0-S SM1-S SM2-S SM3-S
Length m (ft) 0,5 (1.6) 1,0 (3.3) 2,0 (6.6) 3,0 (9.8)
Weight kg (lb) 1,3 (2.9) 2,7 (6.0) 4,3 (9.5) 5,9 (13.0)
Designation Unit SM4-S SM5-S SM7-S SM9-S
Length m (ft) 4,0 (13.1) 5,0 (16.4) 7,0 (23.0) 9,0 (29.5)
Weight kg (lb) 7,1 (15.7) 9,3 (20.5) 12,9 (28.4) 15,1 (33.3)
Designation Unit H25 H25 S H35 H35 S
Swing play mm (in) 1,1 (0.043) 0,8 (0.031) 2,2 (0.1) 1,7 (0.1)
Vibrations 1/min 12,000 12,000 12,000 12,000
Vibrations Hz 200 200 200 200
Vibrator head shape Round Round Round Round
Vibrator head diameter /
diagonal
mm (in) 25 (1.0) 25 (1.0) 35 (1.4) 35 (1.4)
Length of vibrator head mm (in) 440 (17.3) 295 (11.6) 410 (16.1) 310 (12.2)
Weight kg (lb) 1,3 (2.9) 0,8 (1.8) 2,1 (4.7) 1,7 (3.6)
Oil specification Synthetic oil Synthetic oil Synthetic oil Synthetic oil
Oil quantity l 0.010 0.010 0.015 0.015
Designation Unit H45 H45 S H55 H65
Swing play mm (in) 2,7 (0.1) 1,8 (0.1) 3,1 (0.1) 3,2 (0.1)
Vibrations 1/min 12,000 12,000 12,000 12,000
Vibrations Hz 200 200 200 200
Vibrator head shape Round Round Round Round
Vibrator head diameter /
diagonal
mm (in) 45 (1.8) 45 (1.8) 57 (2.2) 65 (2.6)
Length of vibrator head mm (in) 385 (15.2) 305 (12.0) 410 (16.1) 385 (15.2)
Weight kg (lb) 3,4 (7.5) 2,8 (6.2) 5,3 (11.7) 6,2 (13.7)
Oil specification Synthetic oil Synthetic oil Synthetic oil Synthetic oil
Oil quantity l 0.022 0.019 0.033 0.044
