16 Technical data
100_0101_td_0017.fm 40
16.5 Vibrator head HA (optional)
16.6 Extension cable
Only use permitted extension cables, see
chapter Safety.
Find the necessary stranded conductor cross-section of the extension cable in the following table:
Designation Unit H25HA H35HA H45HA H50HA
Swing play mm (in) 2,1 (0.1) 2,1 (0.1) 3,0 (0.1) 3,5 (0.1)
Vibrations 1/min 12,000 12,000 12,000 12,000
Vibrations Hz 200 200 200 200
Vibrator head shape Square Square Square Square
Vibrator head diameter /
diagonal
mm (in) 26 (1.0) 36 (1.4) 45 (1.8) 50 (2.0)
Length of vibrator head mm (in) 380 (15.0) 405 (15.9) 390 (15.4) 395 (15.6)
Weight kg (lb) 1,3 (2.8) 2,3 (5.1) 3,3 (7.3) 3,9 (8.6)
Oil specification Synthetic oil Synthetic oil Synthetic oil Synthetic oil
Oil quantity l 0.010 0.020 0.030 0.050
WARNING
Electrical voltage.
Injury from electric shock.
Check power cable and extension cable for damage.
Only use extension cables whose grounded conductor is connected to the plug and
coupling (only for equipment of class rating I, see chapter Technical data).
NOTICE
You can find the model designation and voltage of your equipment on the nameplate or
using the item number from the chapter Technical data.
Machine Voltage
[V]
Extension
[m]
Cross-section area of cable
[mm
2
]
M1500 US 120 1~ <
25 1,5
<
42 2,5
<
66 4,0
<
98 6,0
<
160 10,0
M2500 US 120 1~ <
21 1,5
<
35 2,5
<
55 4,0
<
82 6,0
<
133 10,0
