BAMBOO TABLET
Active area
This is the active area for pen
and touch input. Learn about
the pen experience
and touch
experience with Bamboo.
Customizable ExpressKeys
USB cable, detachable
Disconnect the USB
cable when storing
Bamboo. Do not wrap
the cable around the
tablet.
Bamboo
(small tablet shown)
Pen holder
Status LED
Glows blue when Bamboo is connected to an active USB
port. Brightens when you touch the active area or press an
ExpressKey.
Glows white when using the pen.
For wireless operation, see battery and wireless connection
status.
Battery compartment,
located beneath tablet
See wireless setup
.
Wacom wireless module slot
Storage compartment, for Wacom
wireless receiver
See going wireless with your Bamboo
.

WACOM CTL-470 Specifications

General

Pressure Levels	1024
Connection	USB
Report Rate	133 pps
Pen Buttons	2
Active Area	152 x 94 mm (6.0 x 3.7 in)
Resolution	2540 lpi
Pen	Battery-free
