BAMBOO PEN TABLET
USB cable, detachable
Disconnect the USB
cable when storing
Bamboo. Do not wrap
the cable around the
tablet.
Bamboo Pen
Status LED
Glows blue when Bamboo is connected to an active
USB port.
Brightens when using the pen.
Pen holder
Active area
This is the active area for pen input.
Learn about your pen
and the pen
experience with Bamboo.

WACOM CTL-470 Specifications

General

Pressure Levels	1024
Connection	USB
Report Rate	133 pps
Pen Buttons	2
Active Area	152 x 94 mm (6.0 x 3.7 in)
Resolution	2540 lpi
Pen	Battery-free
