14
PRIMING
3. TURN SPRAYER ON.
4. Turn PRESSURE CONTROL KNOB between half
and full pressure. See Figure 20. You should then
be able to see the paint move through the suction
tube to the pump. Continue until paint flows through
the return tube. (Let unit prime 1 to 2 minutes).
Figure 20 - Turn Pressure Control Knob
CAUTION
the priming knob. Failure to do so may cause damage to
the paint pump diaphragm.
Always reduce pressure to zero
before changing the position of
CAUTION
Knob is still on spray during sprayer operation, there will
be high pressure in the hose and spray gun until the
Priming Knob is turned to PRIME A or until the spray gun
is triggered to relieve the pressure.
If the Pressure Control Knob is
reduced to zero and the Priming
PRIME THE PUMP
Continued from page 13
To Next Page
