8
Pressure Relief Procedure
Follow this procedure after the unit is assembled and before any operation which involves the spray gun such as
changing tips or accessories, or cleaning and maintenance.
1. Make sure PRESSURE CONTROL KNOB is at its lowest
setting (counterclockwise).
2. Turn PRIMING KNOB to PRIME A position.
3. Trigger gun to remove any pressure which may still be
in the hose.
place. NEVER trigger gun unless tip is completely turned
to the spray or unclog position. ALWAYS engage trigger
lock before removing, replacing or cleaning tip.
Injection hazard possible. Do
not spray without tip guard in
WARNING
4. Lock gun trigger in the Off position.
Pressure Control
Knob
Prime A
Spray B
Knob
Trigger Lock
To Next Page
