If liquids collect in the area underneath the
outlet valve, this could be due to a leak in
the set of pistons. If operations continue, the
liquid can leak and dirt might get under the
device.
Usable materials
•
Dispersion and latex paints for interior use.
•
Water-based and solvent-containing lacquers and
glazes. Paints, oils, release agents, synthetic enamels,
PVC lacquers, undercoats, base coats, llers and anti-rust
paints.
Another tip size and gun lter may be used,
depending on the material to be processed.
Information about all the available tips and
lters can be found in the section about
"Accessories".
Unsuitable materials
•
Materials that contain highly abrasive components,
facade paint, caustic solutions and acidic coating
substances.
•
Flammable materials, materials containing acetone or
cellulose thinner
Field of application
Coating of interior walls as well as small and medium-
sized objects outdoors (e.g. garden fences, garage doors,
etc.).
Industrial use is excluded.
Technical data
Voltage 230-240 V, 50 Hz
Power consumption 350 W
Protection class I
Maximum pressure 11 MPa (110 bar)
Flow rate at 69 bar (0 bar) 0.9 l/min (2.0 l/min)
Maximum temperature of coating
material
43°C
Sound pressure level*
Uncertainty
78 dBA
K= 4 db
Sound pressure output*
Uncertainty
91 dBA
K= 4 db
Oscillation level**
Uncertainty
3.8 m/s²
K = 1.5 m/s²
Maximum ambient temperature 40°C
Pump system piston pump
volume upper container, max. 5.5 l
Max. nozzle size 515 HEA
Max. hose length 22.5 m
Empty weight (pump, hose, gun) 4.1 kg
* Measured in accordance with EN 50580
** Measured in accordance with EN 60745-1
Information about the oscillation level
The specied oscillation level has been measured according
to a standard test procedure and can be used to compare
against electric tools.
The oscillation level is also for determining an initial
assessment of the vibrational strain.
Attention! The vibration emission value can dier from
the specied value when the electric tool is actually in
use, depending on how the electric tool is being used.
It is necessary to specify safety measures to protect the
operating personnel. These measures are based on an
estimated shutdown during the actual conditions of use
(all parts of the operating cycle are taken into consideration
here, for example periods when the electric tool is switched
o, and, when it is switched on but running without any
load).
The rating plate and production code are located on the
underside of the device.
