Make pump ready for operation
1) Make sure the inlet lter is in
place inside the hopper. If it
is not, snap in place as shown.
2)
Press down the button
on the filter once. This
will ensure proper
operation of the inlet valve.
3) Turn the PRIME/SPRAY knob
to PRIME.
4) Plug in the sprayer, and
move the ON/OFF switch to
the ON position.
Button
l
5) Switch the pump to OFF.
O
We recommend performing the following steps with
water rst of all, in order to check that the system and all
connections are watertight.
6) Fill your hopper with the
material you plan to spray.
Do not exceed the ll line as
shown. Replace the hopper
lid.
Fill line
7) Leave the PRIME/SPRAY
knob on PRIME and switch
your unit ON once more
and make sure that material
is owing from the return
tube.
l
Mount the cover during operation. The cover
does not close airtight. Therefore, do not tilt
the device when lled.
Suck in material
Perform the following steps, without the spray tip
mounted to the gun.
1)
Unlock the spray gun and
turn the PRIME/SPRAY knob
to PRIME.
2) Trigger and HOLD the spray
gun into a waste container.
3) Switch the pump on.
WARNING
Keep hands clear from uid
stream.
4)
While holding the trigger,
turn the PRIME/SPRAY knob
to SPRAY. Hold the trigger
until all air, water, or solvent
is purged from the spray hose
and paint is owing freely.
l
5) Release trigger, turn the
PRIME/SPRAY knob to
PRIME and turn pump OFF .
O
6) Trigger the gun into the waste container once more to
be sure that no pressure is left in the hose.
7) Lock the spray gun o.
8) Thread the spray tip assembly onto the gun. Tighten by
hand.
Begin
tightening
the tip at
this angle
to achieve
the desired
spray angle
when tight.
9) Insert spray tip (tip pointing in the spray direction).
Your device is now ready for operation.
Preparation
