OPERATING AND ASSEMBLY MANUAL
VERSION 08/2015 ORDER NUMBER DOC2350372
15.26 HICOATED PUMP P
Pos K Quantity Order No. Designation
241623 HiCoat-ED pump P
1 1 241229 Collector nozzle low air
2 1 241479 Hose sleeve
3 1 241466 Union nut
4 1 241930 Air nozzle
5 1 241460 Spring check valve
6 1 241461 Spring check valve with choke (marked in black)
7 2 9970149 Sealing ring
8 1 9999047 Quick-release plug
9 1 9999048 Quick-release socket
10 1 9970150 Sealing ring
11
2 9974023 O-ring, electrically conductive
Wearing part
Not part of the standard equipment, but available as a special accessory
Only available as a set
