24
PXM
OPERATING AND ASSEMBLY MANUAL
VERSION 08/2015 ORDER NUMBER DOC2350372
Dimensions:
Maximum height 2,660 mm; 104.72 inches
Maximum width 2,170 mm; 85.43 inches
Maximum depth 1,400 mm; 55.12 inches
Weight Approx. 500 kg + 150 kg lter suction
Electrical:
Three-phase current connection 230/400 V 3P/N/PE 50 Hz
Frequency 50 Hz
Total power consumption 1.5 kW (without lter)/3.7 kW (with lter)
Protection class IP 54
Pneumatic:
Compressed air connection 0.6 – 0.8 MPa; 6 – 8 bar; 87 – 116 psi
Cross-section of compressed air line At least 1.5"
Compressed air quality 6.5.2 according to ISO 8573.1: 2010
Air throughput coating mode 45 Nm³/h; 1,588.88 cf/h
Air throughput cleaning mode 100 – 150 Nm/h in approx. 30 sec.
Suction capacity, exhaust 4,000 m³ at 1,300 Pa; 5,230.86 cubic yards at 0.19psi
Filter surface area (version with lter) 40 m²; 430.55 square foot
Number of lters 2
Filter capacity > 99%
Permanent suction output for version with connection to a nal lter: 1,000 Nm/h; 35,308.34 cf
Equipment:
5.5 TECHNICAL DATA
Exhaust air containing oil!
Risk of poisoning if inhaled.
Provide compressed air free from oil and water
(Quality Standard 7.5.4 as per ISO 8573.1, 2010)
7.5.4 = 5-10mg/m³ / ≤7 °C; 44.6 °F / 5 mg/m³.
WARNING
Number of injectors PXM 20/22: 20 injectors when feeding from the box
PXM 20/22: 22 injectors when feeding from the uid tank
PXM 34: 34 injectors when feeding from the uid tank
Ambient conditions:
Operating temperature range 5 – 45 °C; 41 – 113 °F
