WAGNER Force Ten FDX User Manual

22
FORCE TEN
TM
FORCE GAGE
G. GAGE CAPACITY
The FDX force gage capacity is determined by the ratings of the built in load cell and
cannot be changed by the user.
G.1 Overload Protection
• Each FDX is protected against overload.
• Prior to reaching overload limits of the load cell, the gage will indicate an
overload condition by displaying warning messages.
• Safe overload limits are a total of both tared weight and applied test weights.
TABLE 6 SAFE OVERLOAD LIMITS
Units
Capacity
Limit
% of F.S.
lbf
10 / 25 / 50 / 100
15 / 37.5 / 75 / 130
150 / 150 / 150 / 130
kgf
5 / 10 / 25 / 50
7.5 / 15 / 37.7 / 65
150 / 150 / 150 / 130
N
50 / 100 / 250 / 500
75 / 150 / 375 / 650
150 / 150 / 150 / 130
ozf
160 / 400 / 800 / 1600
240 / 600 / 1200 / 2080
150 / 150 / 150 / 130
