1 Spray gun 2 High-pressure hose 3 Electric motor 4 ON/OFF switch 5 Control lamp shows that the unit is ready
for operation HC 35 E, HC 45 E, HC 45 E-SSP
6 Unit connection line (230 V) 7 Extractable shaft 8 Control lamp shows that the unit is ready
for operation HC 55 E, HC 55 E-SSP
9 ON/OFF switch (400 V)
HC 55 E, HC 55 E-SSP
10 V-belt under the belt cover 11 Return hose 12 Suction tube 13 High-pressure filter 14 Material feed pump
HC 45 E, HC 55 E
15 Material feed pump
HC 45 E-SSP, HC 55 E-SSP
Description of unit
3.3 Explanatory diagram legend HC units
16 Material feed pump HC 35 E 17 Manometer 18 Retention pin for the swivel mechanism 19 Filling orifice for separating oil
(separating oil prevents increased wear and tear of the packings)
20 Ball valve lever position horizontal –
hydraulic motor switched off lever position vertical – hydraulic motor switched on
21 Handle for swiveling the material feed pump 22 Hydraulic motor 23 Relief valve knob
Turn left for circulation k Turn right for spray p
24 Hydraulic oil pump 25 Pressure regulating knob 26 Oil measuring stick
