HC 35 E • HC 45 E • HC 55 E 39
g
3.6 Transport
Push unit.
Pull out shaft (fig. 4, item 1) until it will come no further.
Insert shaft – push buttons (2) on the spars, and then in-
sert shaft.
Description of unit
1
2
2
1
2
3
3.7 Transport in vehicle
Pull retention pin (fig. 5, item 1) in the swivel mechanism
(2) for the material feed pump (3) and swivel it to a hori-
zontal position. Ensure that the retention pin locks.
Roll the high-pressure hose over the suspension device
at the shaft.
Secure the unit with a suitable fastening.
