OPERATING MANUAL
VERSION 01/2013 ORDER NUMBER DOC 2333538
Incorrect maintenance/repair!
Danger to life and equipment damage.
Only a WAGNER service center or a suitably trained person may
carry out repairs and replace parts.
Only repair and replace parts that are listed in the chapter "Spare
Parts Catalogue" and that are assigned to the device.
Before all work on the device and in the event of work
interruptions:
- Disconnect the control device from the mains.
- Relieve the pressure from the spray gun and device.
- Secure the spray gun against actuation.
Always follow the operating and service instructions at all times
when carrying out work.
WARNING
Ball valve version in: Stainless steel Carbon steel
Designation Order No. Order No.
1 1 HP lter DN12-PN530, complete 2329025 2335334
2 1 Filter housing 2324542
3 1 Union nut 2324543
4 1 Reducing double nipple with 2x60° 2330780
5
1 O-ring 9955863
7 1 Distribution housing for ball valve 2324670
10 1 Filter support 9894245
11
1 Filter sieve *
* Filter sieve 200 295721
* Filter sieve 100 3514068
* Filter sieve 50 3514069
* Filter sieve 20 291564
12
1 Cone spring 3514058
13 1 Reducing nipple 2328291
20 1 Ball valve 2330156 9998679
21 1 Pressure ring d45 2325562
23 1 Hexagon plug 2323718
33
1 Double connection 3204611 2325826
34 1 Loctite 542 50 ml; 50 cc 9992831
35 1 Grease mobilux EP 2 9998808
36 1 Anti-sieze paste tube 9992609
