Wagner Project Pro 117 - 0418B
Components and Description
The shipping carton for your painting system contains the following:
•Suctiontubeandreturntube(includinginletlterand3clips) •Spraytipassembly
 • Basicunit       •7.5m,6.35mminternaldiameterpressurehose
 • Spraygunwithtwolters(L-XXL;oneingun,oneseparate)  •Oilask
 • Instructionmanual
Figure 1 - Controls and Functions
(further, detailed descriptions of the individual items can be found in the relevant section of the operating instructions)
Item Component Description
 A) ON/OFFSwitch ............................TheON/OFFswitchturnsthepowertothesprayeronando(O=OFF,l=ON).
 B) PRIME/SPRAYKnob ....................ThePRIME/SPRAYknobdirectsuidtothesprayhosewhensettoSPRAYorthereturntubewhenset
toPRIME.ThearrowsonthePRIME/SPRAYknobshowstherotationdirectionsforPRIMEandSPRAY.
ThePRIME/SPRAYknobisalsousedtorelievepressurebuiltupinthesprayhose(seePressureRelief
Procedure).
 C) Quicko™Valve .............................TheQuicko™valveisdesignedtokeeptheinletvalveopenandfromstickingtodriedmaterials.
TheQuicko™valveisactivatedmanuallybytheuser.
 D) PressureTrac™ ................................ThePressureTrac™regulatestheamountofforcethepumpusestopushtheuid.
 E) PumpSection .................................Apistoninthepumpsectionmovesupanddowntocreatethesuctionthatdrawsuidthroughthe
suction tube.
 F) SuctionTube ..................................Fluid is drawn through the suction tube into the pump.
G) Return Tube ....................................FluidissentbackoutthroughthereturntubetotheoriginalcontainerwhenPRIME/SPRAYknobisin
PRIME position.
H) Inlet lter ..........................................The inlet lter strains the spray material to prevent the system from becoming clogged.
 I) SprayGun ........................................For application of the coating material and regulation of the pump capacity.
 J) SprayHose ......................................The spray hose connects the gun to the pump.
When working outdoors:
Danger
Vapors containing solvents may not be allowed to
blow toward the unit.
Note the direction of the wind.
Set the unit up in such a way that vapors containing
solvents do not reach the unit and build up there.
A minimum distance of 5 m between the unit and
spray gun is to be maintained.
U Cleaning the unit
Danger
Danger of short circuit through penetrating water!
Never spray down the unit with high-pressure or
high-pressure steam cleaners.
U Cleaning units with solvents
Danger
When cleaning the unit with solvents, the solvent
should never be sprayed or pumped back into a
container with a small opening (bunghole). An
explosive gas/air mixture can be produced. The
container must be earthed.
Do not clean the device or accessories with
ammable solvents with a ash point below 21 °C.
U Earthing of the object
The object to be coated must be earthed.
Technical Data
Pump type Piston pump
Power source 230-240V
~
50 Hz
Power consumption 670 W
Fusing
Onlyconnecttosocketsprotected
with an FI fuse (16 A)
Double insulation
Max. spray pressure 200 bar
Max. delivery rate 1,0 l/min
Soundpressurelevel 71,4 dB (A)
Oscillationlevel < 2,5 m/s²
Max. temperature of coating
substance 40°C
Max. nozzle size XL(0,019")
Hose length 7,5 m
Weight 7,8 kg
CoatingMaterialsSuitableforUse
Water-based and solvent-containing lacquers and glazes.
Paints,oils,releaseagents,syntheticenamels,PVClacquers,
undercoats, base coats, llers and anti-rust paints.
Dispersion and latex paints for interior use.
CoatingMaterialsNotSuitableforUse
Materials that contain highly abrasive components, facade paint,
caustic solutions and acidic coating substances.
Materialswithaashpointbelow21°C.
i
In order to ensure compatibility of the coating substance
with the materials used to manufacture the device, please
contactWagnerServiceincasesofdoubt.
