7
eN
troubleshootiNg
problem cause solutioN
Problem A: There is
leakage on the roller
arm assembly.
1. The roller arm seal is backwards.
2. The roller arm seal was not properly
cleaned.
3. The O-ring and the connecting
areas on the roller arm were not
cleaned properly.
4. Residue on the connecting area
inside of the head.
5. The O-ring on the roller arm is
damaged or missing.
6. The roller cover is worn or
damaged.
7. The roller core or cap is worn or
damaged.
1. Turn the seal around.
2. Clean and properly lubricate.
3. Clean and properly lubricate
(see Cleanup and Storage
pages 4-6).
4. Clean out any remaining residue
inside the head of the SMART
Roller.
5. Clean or replace*.
6. Replace the roller cover*.
7. Replace the roller core or cap*.
Problem B: Plunger is
dicult to pull/push.
1. The plunger O-rings are not
lubricated.
1. Lubricate the plunger
O-rings (see Lubricating the
components, page 6)
Problem C: The main
tube will not ll, or
there is leakage from
the ll valve.
1. Residue on the ll valve
components.
a) Insert the ll tube into the ll
valve and twist the ll tube
several times to break up the
residue.
b) If the problem persists, refer to
Cleaning the ll valve, page 5.
* Replacement parts available by calling customer service
Have you tried the recommendations above and are still having
problems? In the United States, to speak to a customer service
representative, call our Technical Service at 1-800-760-3844 Monday
through Friday between 8:00 AM and 4:30 PM Central time.
product reGiStration
In order to register your product today, visit:
www.wagnerspraytech.com/registration
We value your opinion. To complete your review, please visit:
www.wagnerspraytech.com/reviews
