104 Commissioning WAGO-I/O-SYSTEM 750
750-363/0040-0000 FC EtherNet/IP G4 ECO XTR
Manual
Version 1.0.0
8.3.4.1 Reasons for Failed IP Address Assignment
• The PC on whom the BootP server is running is not located in the network
as the fieldbus coupler/controller; i.e., the IP addresses do not match.
Example:
Sub net mask: 255.255.255.0
(default value for a fieldbus
coupler/
controller n)
PC‘s IP: 192.168.2.100
fieldbus coupler/controller‘s IP: 192.168.1.200
Due to the sub net mask, the first 3 digits of the IP addresses must match.
• PC and/or head station is/are not linked to the ETHERNET
