5.5 Assembly Sequence
All system components can be snapped directly on a carrier rail in accordance
with the European standard EN 50022 (DIN 35).
The reliable positioning and connection is made using a tongue and groove
system. Due to the automatic locking, the individual components are securely
seated on the rail after installation.
Starting with the coupler/controller, the bus modules are assembled adjacent to
each other according to the project design. Errors in the design of the node in
terms of the potential groups (connection via the power contacts) are recognized,
as the bus modules with power contacts (male contacts) cannot be linked to bus
modules with fewer power contacts.
Pos: 61.8 /Serie 750 (W AGO-I/O-SYSTEM)/Wi chtige Erläuterungen/Si cherheitshinwei se/Vorsicht/Vorsi cht: Verletzungsgefa hr durch scharfkantig e Messerkontakte! @ 6\ mod_1256193279401_21. doc @ 43414 @ @ 1
Risk of injury due to sharp-edged male contacts!
The male contacts are sharp-edged. Handle the module carefully to prevent injury.
Pos: 61.9 /Serie 750 (W AGO-I/O-SYSTEM)/Wi chtige Erläuterungen/Si cherheitshinweise/ Achtung/Achtun g: Busklemmen in vorgegeben er Reihenfolge stec ken! @ 6\mod_12561941770 73_21.doc @ 43429 @ @ 1
Connect the I/O modules in the required order!
Never plug bus modules from the direction of the end terminal. A ground wire
power contact, which is inserted into a terminal without contacts, e.g. a 4-channel
digital input module, has a decreased air and creepage distance to the neighboring
contact in the example DI4.
Pos: 61.10 /Serie 750 (W AGO-I/O-SYSTEM)/W ichtige Erläuterungen/Si cherheitshin weise/Achtung/Achtu ng: Aneinanderreihen von Busklemmen nur bei off ener Nut! @ 6\mod_125619335144 8_21.doc @ 43417 @ @ 1
Assemble the I/O modules in rows only if the grooves are open!
Please take into consideration that some bus modules have no or only a few power
jumper contacts. The design of some modules does not allow them to be
physically assembled in rows, as the grooves for the male contacts are closed at
the top.
Pos: 61.11 /Serie 750 (W AGO-I/O-SYSTEM)/W ichtige Erläuterungen/Si cherheitshin weise/Hinweis/Hin weis: Busabschluss nic ht vergessen! @ 6\mod_1256194225557_21.doc @ 43432 @ @ 1
Don't forget the bus end module!
Always plug a bus end module 750-600 onto the end of the fieldbus node! You
must always use a bus end module at all fieldbus nodes with the WAGO I/O
System 750 fieldbus couplers/controllers to guarantee proper data transfer.
Pos: 61.12 /Dokumenta tion allgemein/Glied erungselemente/---Seitenwechsel--- @ 3\mod_122110804 5078_0.doc @ 21810 @ @ 1

WAGO 750-880 Specifications

General

Data Memory	128 KB
Real-time Clock	Yes
Supply Voltage	24 VDC
System Power Supply	24 VDC
Number of I/O Modules	Up to 64
Protection Type	IP20
Relative Humidity	95 % (non-condensing)
Bus System	Ethernet
Interfaces	Ethernet, RS-232
Operating Temperature	-25 °C to +60 °C
Storage Temperature	-40°C to 85°C
Data Rate	10/100 Mbit/s (Ethernet)
Programming Languages	IEC 61131-3
Data Transfer Rate	10/100 Mbit/s
Fieldbus Protocols	MODBUS/TCP
Product Type	Programmable Fieldbus Controller
