14 • Quick Start
Starting up the Bluetooth® Modules
WAGO-I/O-SYSTEM 750
I/O Modules
The following section describes how to select the devices required to establish
connection to the master. Devices that are visible for search requests can first
be searched for in a similar way to slave's configuration (see Section 2.2.1,
steps 9-12). They may then be stored using "Drag & Drop", for example, from
the search results into the list of authorized devices (slots 1…13). However,
for safety reasons, WAGO devices are hidden for search request in communi-
cation operating mode; they may also be entered like other hidden devices or
inaccessible devices:
10. Enter the listed MAC address of the slave, which is already set in the
communication operating mode, manually in the allocated field. The fol-
lowing steps assume that you are using slot 1.
11. Give the newly added device a name (UserFriendlyName); e.g.,
"Slave_01". This makes the overview easier for you.
12. Mark the slot with the entered MAC address and choose the value "Yes" in
the dropdown field Bind.
13. Click on the [Write] button in the toolbar to write the altered configura-
tion in the module.
Master and slave are now assigned to each other. The master is still in con-
figuration mode.
