WAGO-I/O-SYSTEM 750 Appendix 143
750-657 IO-Link Master
Manual
Version 1.0.2, valid from FW/HW-Version 02/01
Table 135: sercos process data
IDN/S-0-1500.0.05 “Container OutputData“ (Default)
Byte Designation Note
0 C0 Steuerbyte
1 FC0 Acyclic channel / register byte 0
2 MB0 Mailbox byte / register byte 1
3 SIO SIO byte
4 D0
… …
23 D19
Data bytes
IDN/S-0-1500.0.09 “Container InputData“ (Default)
Byte Designation Note
0 S0 Status byte
1 FC0 Acyclic channel / register byte 0
2 MB0 Mailbox byte / register byte 1
3 SIO SIO byte
4 D0
... ...
23 D19
Data bytes
More information about sercos parameter model
More information about the parameter model in sercos and about using the listed
fieldbus parameters is available in the sercos specification v1.1 (sercos
International e.V., http://www.sercos.org) and in the user manual of the WAGO
sercos fieldbus coupler 750-351 on the Internet at http://www.wago.com 
Documentation  WAGO-I/O-SYSTEM 750.
