WAGO-I/O-SYSTEM 750 Appendix 91
750-657 IO-Link Master
Manual
Version 1.0.2, valid from FW/HW-Version 02/01
11.1.2.1.2 Access to Data Areas
Access to the different data areas is shown in the following table:
Table 55: Access to Data Areas
Data area Entity_Port FI_Index IO-Link index IO-Link subindex
I&M0 0 0 * *
I&M1 0 1 * *
I&M2 0 2 * *
I&M3 0 3 * *
I&M4 0 4 * *
IOL-M Basic Configuration 0 98 0x100 0
IOL-M-Port 1 0 98 0x200 0
IOL-M-Port 2 0 98 0x300 0
IOL-M-Port 3 0 98 0x400 0
IOL-M-Port 4 0 98 0x500 0
Command register 0 98 0x1000 0
IOL-M Directory 0 99 * *
ISDU 1 98 Acc. to IOL spec. Acc. to IOL spec.
ISDU 2 98 Acc. to IOL spec. Acc. to IOL spec.
ISDU 3 98 Acc. to IOL spec. Acc. to IOL spec.
ISDU 4 98 Acc. to IOL spec. Acc. to IOL spec.
* Not required
