The assembled drawer with
this warning must be placed
on top of the unit.
I
I
I
D
Ø3,5*30mm
20
Step 14
P.11
Insert part 14 between parts 11 and 12.
screws(D), and Phillips head screwdriver.
Attach part 13 to parts 11 and 12 with
D
D
D
D
D
5x
13
14
Step 15
I
Ø8*40mm
10
Insert wood dowel (I) on the inside of
all drawers, with the drawer inside the unit
after having passed the wood dowel that is in the drawer slide.
The dowel is not flush with the panel, it is a
to remove the lock dowel to remove the drawer.
little inside the drawer to help when you need
11
12
To Next Page
