Walker Edison BWJRTOL - Step 11: Guard Rail Support Installation

Walker Edison BWJRTOL
23 pages
Print Icon
To Next Page IconTo Next Page
To Next Page IconTo Next Page
To Previous Page IconTo Previous Page
To Previous Page IconTo Previous Page
Loading...
P.10
J
06
4,0x30
05
J
J
J
J
J
J
36 3/8"
29 1/2"
Connect guard rail support (05) to guard rail (17,18)
and bed rail (20,21) using screw (J).
Follow measurements shown in diagram.
Step 11
05
