Philips head screwdriver required
for assembly (not included)
P.4
The hardware quantities listed above are required for proper assembly.
Some extra hardware may also have been included.
Hardware List
Slotted head screwdriver required
for assembly (not included)
C
04 pcs
D
Hex key
01 pc
E
Nut
04 pcs
ø1/4"*90mm
Bolt
B
14 pcs
ø7,0"*80mm
Bolt
A
18 pcs
ø7,0"*40mm
Bolt
F
Screw
34 pcs
J
Support
04 pcs
ø4.0*16mm
ø4.0*30mm
I
Screw
16 pcs
G
Space Block
02 pcs
K
Dowel
10 pcs
ø10*40mm
81mm
To Next Page
