Walker Edison Cama CMAB8B - Página 7

P.7
Step 5
Step 6
C+D
E
4
7
01
D
01
E
E
C
D
01
D
D
B
01
C
ø1/4"*90mm
01
B
ø7,0"*80mm
7
B+D
!
C
E
Attach part 7 with the post 4, fix with screw C and nut E using a
Hex Key D. If necessary, use a flathead screwdriver.
Attach part 7 with the Headboard Right Post 4, fix with the screw B
using the hex key D.
"If necessary, use a slotted head screwdriver»
