Walker MS - Page 32

Operating Instructions
28
Operating Controls (Top View from Drivers Point of View)
BLADE CLUTCH
(PTO)
Neutral-Park
Position
RIGHT WHEEL
STEERING LEVER
CHOKE
PARKING
BRAKE
THROTTLE
OFF Position
ON Position
The Forward Speed Control also Establishes the Neutral-Park Position of the Steering Levers
Full Forward
Ground Speed
Position
Intermediate
Ground Speed
Position
Reverse Drive
Wheel Motion
Position
Neutral-Park
Position
Fast
Throttle
Position
Idle
Position
Engaged
Position
Disengaged
Position
FORWARD SPEED
CONTROL LEVER (FSC)
Disengaged
Position
Engaged
Position
LEFT WHEEL
STEERING LEVER
Forward Position
(No Control Change)
