Maintenance Instructions CLEANING
50
CLEANING
CAUTION
If a pressure washer is used on the ex-
posed working parts, avoid water on the
electrical parts and the engine cooling sys-
tem.
Engine Air Cleaner System
Donaldson Radialseal™ Air Cleaner
A remote mounted Donaldson Radialseal™ air
cleaner provides the air ltering function. The paper
lter element slides over an outlet tube inside the air
cleaner canister with radial sealing action, eliminat-
ing the possibility of dust leaks due to improper lter
installation. Intake design, internal bafing, and a
dust ejection valve provide dust separation and au-
tomatic precleaning action. Daily or frequent servic-
ing of the air cleaner is not required. Use the air
lter restriction indicator on the air cleaner outlet to
indicate when the air lter needs servicing -- a yel-
low indicator will show when the lter is overly re-
stricting airow into the engine.
IMPORTANT: Use only Donaldson air lter ele-
ments for replacement (Donaldson P822686 or
Walker 5090-1). Aftermarket lters may not seal
properly or lter efciently.
Primary
Filter Element
Canister
Dust Ejection
Valve
Cover
Cover Latch
Air Cleaner Components
(Shown with Cover Being Removed)
IMPORTANT: The Donaldson air cleaner uses a dry
paper-type air lter element. NEVER apply oil to the
paper element.
Engine Air Cleaner System Components
Donaldson Air
Cleaner Cover
Engine
Dust Ejection
Valve
Safety
Filter
Donaldson
Air Cleaner
Elbow
Primary Filter
Element
1/8 Pipe Thread
Male W/Barb
Vacuum Hose
Hose
Clamp
Intake
Tube
Intake Pipe /
Gasket
Air Intake
Hose
Hose
Clamp
Air Filter
Restriction
Gauge
