61
Maintenance Instructions REPLACING/REPAIRING
REPLACING/REPAIRING
DANGER
To prevent accidental starting of the en-
gine when replacing parts or repairing the
machine, remove the key from the ignition
switch and disconnect the spark plug
wire.
IMPORTANT: ALWAYS use genuine factory re-
placement parts. Substitute parts CAN result in
product malfunction and possible injury to the op-
erator and/or others.
Drive Belts
There are three (3) individual belts on the ma-
chine:
• Engine Belt
• PTO Drive Belt
• Ground Drive Belt
The belts may be removed and replaced using the
procedures described on the following pages.
Engine Belt
PTO Drive Belt
Ground Drive Belt
Belt Locations
