Maintenance Instructions LUBRICATION
46
Ident Lubrication No.
No. Location Type Places
Ident Lubrication No.
No. Location Type Places
1 Deck Caster Wheel Fork Pivot Grease 2
2 Blade Drive Gearbox Oil* 2
3 Tee Gearbox, Deck Oil* 1
4 Deck Caster Wheel Bearing Grease 2
5 Universal Joint Shaft Assembly Grease** 1
6 Pivot Assembly, Tilt-Up Deck Grease 4
7 Deck Support Arm Socket Grease 2
8 Steering Lever Pivot Grease 4
9 Body Hinge Point Oil 2
10 FSC Actuator Rod Pivot Pins Oil 2
11 FSC Lever Pivot Grease 1
12 FSC Lever Fork Grease 1
(Grease Slide Area)
13 (FSC) Friction Body Pivot Grease 1
14 Deck-to-PTO Coupling Grease 1
(Grease Spline Slide Area)
15 Deck Support Arm Pivot Grease 2
16 Universal Joint Tube Assembly Grease** 1
17 Parking Brake Lever Grease 1
18 Pillowblock Bearing, Drive Shaft Grease
Δ
2
19 Gear Axle Oil*** 2
20 Clutch Control Lever Pivot Grease 1
21 Clutch Actuator Rod Grease 1
(Grease Slide Area)
22 PTO Belt Tightener Pivot Grease 1
23 Scrubber Brake Linkage Oil 2
24 Engine Dipstick / Oil Filler Oil*** 1
25 Catcher Hinge Point Oil 2
26 Choke Control Cable Ends Oil 2
27 Throttle Control Cable Ends Oil 2
28 Engine Belt Tightener Pivot Grease 1
29 Right Angle Gearbox, Tractor Oil*** 1
30 Hydrostatic Drive Oil*** 2
31 Ground Drive Belt Tightener Pivot Grease 1
32 Choke Control Pivot Oil 1
33 Throttle Control Pivot Oil 1
* Gearboxes are permanently lubricated and sealed requiring
no scheduled lubrication. Oil level should be checked only
when an oil leak is noted.
** Grease every eight (8) hours.
*** Refer to Gear Axle Lubrication, Engine Oil, Tractor PTO
Gearbox Lubrication, and Hydrostatic Transmission
Fluid in this sec tion.
Δ Sealed, relubricatable-type bearings, grease lightly once per
year, do not over grease or seals will be damaged.
NOTE: DGHS42 Tilt-Up Deck is shown for reference. For other
Deck Lubrication Points, Refer to Deck and Carrier
Frame Illustrated Parts Manual.
