English - 17 -
content. If you decline an upgrade, you will not be able
to access content that requires the upgrade.
6SHFL¿FDWLRQV
General
Power supply for set-top box : 12V DC - 220 - 240 V
AC, 50-60Hz
Input Frequency : 470 MHz - 854 MHz
Power consumption : 22 W (max)
Operating temperature : 5ºC to +40ºC
Storage temperature : -20ºC to +70ºC
Humidity : 25 to 75 % rel
Physical dimensions : 230,60 x 138,50 x 42,50 mm
Weight : 580 g
Standby Low power consumption : Less than 0.5W
USB
Current Limit : 500mA
Remote Control
Operating Distance : 7m Max.
Batteries : 2x1.5V (R-03/AAA)
DVB-S/S2 Compliant
Frequency Range (Satellite): 950 MHz -2150 MHz
Ku band reception: 10.7 – 12.75 GHz
LNB Control: Horizontal/vertical polarity switching
(18/13V +/- %7,5), 0-22 kHz switching, tone burst A/B
switching for dish selection,DiSEqC 1.x compliant,
LNB short circuit and overload protection by software
FTA (Free- to- Air) search option for satellite and auto
search modes
DVB-T/T2 Compliant
Frequency Range(Terresterial): 174-864Mhz for
DVB-T/T2
Channel BW(Terresterial): 7 MHz / 8 MHz
Digital Capabilities
Transmission Standards:
MPEG2, MPEG4 DVB-T/T2
MPEG2, MPEG4 DVB-S/S2
Demodulation:
Symbol rate
DVB T2 FFT Modes: 1K/2K/4K/8K/16K/32K
DVB-T FFT Modes: 2K/8K
DVB T2 Constellations: QPSK, 16-QAM, 64-QAM
and 256-QAM
DVB T Constellations: QPSK, 16-QAM, 64-QAM
DVB T2 FEC Codes: 1/2, 3/5, 2/3, 3/4, 4/5, 5/6,
2/5, 1/3
DVB T FEC Codes: 1/2, 2/3, 3/4, 5/6, 7/8
DVB T2 Guard Intervals: 1/128, 1/32, 1/16, 19/256,
1/8, 19/128 and 1/4
DVB T Guard Intervals: 1/32, 1/16, 19/256, 1/8,
19/128 and 1/4
DVB T2 Pilot Patterns: PP1, PP2, PP3, PP4, PP5,
PP6, PP7, PP8
DVB T2 PLPs: Single PLP, Multiple PLP
Modulation
DVB-T/T2
16-QAM - 64-QAM FEC for all DVB modes
(automatically found), 256-QAM for DVB-T2.
DVB-S/S2
Demodulation Types: QPSK, 8PSK, 16APSK and
32APSK
Channel bit rate up to 130Mbps
Symbol rate from 1Msps to 53Msps
V
ideo:
MPEG-1/2/4 Video Decoder
Supports ISO/IEC 13818-2 MPEG-2 MP@HL video
decoding up to 1080p@30fps
Supports ISO/IEC 14496-2 MPEG-4 SP and ASP
video decoding up to 1080p@30fps
H.264 Decoder
Supports ITU-T H.264, ISO/IEC 14496-10 main and
high profile up to level 4.1 video decoding
Supports resolution up to 1080p@30fps
Audio:
MPEG-1, MPEG-2 (Layer I/II), MP3, AC-3 (Dolby
Digital), AAC-LC
E-AC-3 (Dolby Digital Plus)
AAC, HE-AAC 5.1 multi-channel decoding
Simultaneously supports HE-AAC decoding and
transcoding to AC-3
AC-3 stream output through SPDIF
Stereo audio description decoding
RA8-LBR decoding
Media Player
Supported files: mp3, jpeg, avi, mkv
Trick modes: Available
MP3 ID3 Tag support: Available
Mpeg4 file and MKV Playback: Available
Rotate: Available
