Equipment controls
B) Front and back view of the machine
ON/OFF button Control panel
Large wand hose
quick connect
(electrical, air and
solution supply lines)
Connect the hose to
the adaptor by rotating
the quick-connect part
of the hose clockwise
and making sure the
white dot ends in
the locked position
A ccessory Outlet
(Marking and
Mini-Wand port)
Ground Connector
SURFOX electrolyte
solutions
filling and tank
Cleaning pad
mounting unit
Wand holder
Compressed air
connector
Power cord
