Chapter: Safety notes
Prescribed use
2-2
2.2 Prescribed use
The pumps are designed for commercial use.
The pumps may only be used according to the specications in the
documentation of Pumpenfabrik Wangen GmbH.
The operating points below should be seen as limits and should not be
exceeded.
Operating location
Installation: Horizontal
Limits conveying medium
Viscosity: 200.000 mpas
Interfering body size: ø51 mm
pH-value.: 3
Temperature: 0 °C - 60 °C
Limits environment
Temperature: 0 °C - 40 °C
The view direction is to be determined from the rear of the drive to the
direction of rotation. The direction of rotation arrow on the name plate in
addition, the direction of rotation left.
CAUTION!
Failure to comply with the limited values will shorten the life of the pump.
Possible damade to property.
• Operate the pump in accordance with the limits.
