Chapter: Commissioning and recomming
Mechanical connection
3-2
3.4 Mechanical connection
3.5 Electrical connection
The screw connections of the anges must be provided in accordance with
DIN EN 1092-1(PN16) or ASME 16.5 (150lbs). The inner diameter of the seal
must be 105mm/ 4,2in. The preferred sealing material is aramid ber com-
posite. The tightening torque of the screw connection (material 8.8) pump/
piping is 210Nm.
The screw connection between the pump and the installation site must be
executed with ISO 4017 M12x30 or UNC 1/2“ x1 1/4“ hexagon bols. It is de-
pending on the installation site to provide suitable anchor material. The tigh-
tening torque of the screw connetion (material 8.8) pump/ installation site is
89Nm.
Work instructions:
1. Alignment of the pump (bubble level)
2. Marking the drill holes at the installation site
3. Screw connection pump/ piping vertical
4. Screw connection pump/ piping horzontal
5. Screw connection pump/ intallation site
Requirement for the pump connection is a main voltage 230/400V (single-
phase/ tree- phase). Check the information on the nameplate of the drive
whether this matches your situation.
The pump is suitable for operation with and without frequency converter. It
is important to ensure that the connection of the drives is dierent from the
network right on with frequency. All work must be carried out by qualied
personnel (eg electrician)
A variation of the main voltage can cause damage to property.
Improper operating points of the pump. Damage to the dirve
• Checking the drive data (nameplate) to the local conditions
CAUTION!
