Chapter: Maintenance and repair
Pump set (Rotor/ Stator) - Assembly/Disassembly
4-1
4. Maintenance and repair
4.1 Pump set (Rotor/ Stator) - Assembly/Disassembly
4.1.1 Preperation
4.1.2 Assembly/ Disassembly
1. Before starting work, Ensure the absence of voltge and secure it against
inadvertent reconnection.
2. Remove (2022) protective guard.
Personal protective equipment:
- Safety goggles
- Security shoes (steel toed)
- Hearing Protection
- Gloves
Tools:
- Combination wrench for M8, M12 (1/4“), M16 (3/8“)
- Slotted screwdriver 6,5mm x150mm (2x)
- Disruptive discharge ø10mm
- Hammer 250g
- crane
- Round sling (2x)
DANGER!
Danger of beeing pulled in by accidental restarting the pump.
Death or serious bodily injury.
• Remove the connection for the power supply
• Lock the main switch
