Chapter: Maintenance and repair
Pump set (Rotor/ Stator) - Assembly/Disassembly
4-2
3. Position the driveshaft.
4. Close the shut o devices (spool valves in locking position).
5. Open the screw plug (1189) with seal (1013).
6. Remove on both sides the service cover(1521) with at seal (1522).
