Wangen XPRESS 64 - Page 80

Chapter: Maintenance and repair
Pump set (Rotor/ Stator) - Assembly/Disassembly
4-3
7. Move the (1187) snap ring.
8. Press out the connection pin (1627) with O-ring (1628 )(2x).
9. Remove the screw connetion at the disscharge nozzle.
