5. Slide winch into place and secure using hardware that came
with your winch.
6. Attach the fairlead to fairlead bracket.
7. Secure fairlead bracket to winch mount.
8. Tighten all hardware (refer to page 2 for specications).
9. The winch mount, winch, fairlead bracket and fairlead are
now ready to install as one unit.
INSTALLATION INSTRUCTIONS
Figure 5
Figure 6
Figure 7
Figure 8
