10. Slide the assembled winch unit into position (same area
where you removed the welds).
11. Secure with remaining fasteners provided and tighten.
NOTE: For 570 Models: You will need to reverse the direction
of bolts to allow for clearance. Figure 11.
Figure 9
Figure 10
Figure 11
