PARTS LIST
ITEM PART NUMBER DESCRIPTION QTY
A1 83543 WINCH PLATE 1
A2 28885 SPACER PLATE 2
ITEM PART NUMBER DESCRIPTION QTY
B1 79463 M10 HEX FLANGE HEAD BOLT 2
B2 29926 M10 FLAT WASHER 2
B3 79463 M10 FLANGE NUT 2
B4 87165 M10 SOCKET HEAD BOLT 2
B5 69807 M10 LOCK NUT 2
B6 2228 3/8 HEX HEAD BOLT 2
B7 1829 3/8 LOCK WASHER 2
B8 2195 3/8 FLAT WASHER 2
