INSTALLATION INSTRUCTIONS
1. Remove grille by pushing down on grilel tabs and pull grille
outward.
2. Remove the bumper top mounting bolts. Retain hardware,
you will reinstall in a later step.
3. Remove the lower bumper mounting bolts. Retain
hardware, you will reinstall in a later step.
Figure 1
