Warn 103209 - Pre-Installation Checks; Tools and Torque Specifications

To Next Page

To Previous Page

NOTICE

EQUIPMENT DAMAGE

• Always refer to the Installation and Specication Guide, supplied in the winch kit, for all wiring schematics and specic details on how to wire this WARN product to your vehicle.

Read installation and operating instructions thoroughly.

CAUTION

MOVING PARTS ENTANGLEMENT HAZARD

Failure to observe these instructions could lead to minor or moderate injury

• Always take time to fully read and understand the installation and Operations Guide included with this product.

• Never operate this product if you are under 16 years of age.

• Never operate this product when under the inuence of drugs, alcohol or medications.

Read installation and operating instructions thoroughly.

TABLE OF CONTENTS

Tools Required ............................................................................................................................. page 2

Torque Specications ................................................................................................................page 2

Parts List.........................................................................................................................................page 3

Installation ............................................................................................................................. page 4-8

Maintenance/Care ................................................................................................................... page 8

TOOLS REQUIRED

- Standard wrenches

- Standard sockets

- Reciprocal saw or other cutting tool

BEFORE YOU BEGIN

NOTICE

This product may interfere with driver assist systems such as adaptive cruise control and parking assist systems that have sensors or cameras installed in

the bumpers or front grill area. If your vehicle is equipped with any of these systems or features, consult your vehicle owner’s manual before installing

this product. These systems may need to be disabled as a result of installing this product.

TORQUE SPECIFICATIONS

Please use the recommended torque specications when assembling this product unless otherwise specied in the instructions.

FASTENER SIZE FASTENER TORQUE FASTENER SIZE FASTENER TORQUE

lb-ft (N.m) lb-ft (N.m)

1/4" 8 (11) M4 (2) 3

5/16" 17 (23) M5 (4.5) 6

3/8" 30 (40) M6 (7.5) 10

7/16” 48 (66) M8 (18) 25

1/2" 74 (100) M10 (37) 50

9/16” 106 (144)

5/8" 148 (200)
