INSTALLATION INSTRUCTIONS
1. Using a 10mm socket, remove grille by removing the four
front center screws, as well as the two outer push pins.
2. Remove one plastic clip from fender liner (both sides).
3. Using a 17mm socket, remove the two bolts securing the
tow hook (each side). Remove tow hook and set aside. Save
tow hook and bolts for reuse.
Figure 1
Figure 2
Figure 3
Plastic clips
10mm bolts
Plastic clip
To Next Page
